Portable Airtightness Testing Equipment

Product Introduction

Widely Applicable with Full-Scenario Coverage: Suitable for air tightness testing of battery packs, liquid cooling plates, household appliances, military industry, medical industry, 3C industry, automotive industry, etc.—Multi-Purpose in One Machine.

Diverse Detection Methods: Integrates multiple detection methods including positive pressure, negative pressure, differential pressure, positive volume, reverse volume, micro volume, etc., to meet various detection requirements.

Flexible Expandability: Supports customizable test ports and multi-channel parallel testing (e.g., simultaneous testing of 4 battery liquid cooling plates). Fixtures are customized on demand to be compatible with special-shaped parts.

Precise Pressure Regulation: Supply air pressure range is 0.4-0.8MPa, clean, oil-free and water-free, ensuring test stability.

Strong Environmental Adaptability: Operating ambient temperature ranges from 0~50℃, and humidity is below 90% RH, adapting to various scenarios.

Convenient Interaction: Equipped with a 10-inch human-machine interface (HMI) for intuitive operation and enhanced user experience. Multi-Language Support: Supports Chinese, English, Japanese, German, French, Russian, etc., catering to different users.

Large Program Storage Capacity: Supports 1000 sets of executable programs by default, meeting the detection needs of various products. Standardized Data Export: Supports exporting historical records to a USB flash drive via USB interface for easy data management.

Multi-Channel Detection: The standard leak detector supports up to 4 channels of simultaneous testing, with optional multi-channel detection function available.

Strict Permission Management: Adopts a three-level permission system (operator, technician, engineer) to ensure operational safety.

Waterproof Rating Adaptability: Supports test pressure settings corresponding to IPX5 to IPX8 waterproof ratings, with a reference air pressure range of 3~100kPa.
